CE-TD2405
- Category:
COB DOWNLIGHT
- CCT:3000K/4000K/6500K
- Power: 24W
- Rate luminous flux (lumen) : 2160lm
- Ra: ≥80
- Luminous Efficency: 90Im/W
- Input Voltage: 220-240V~,50/60Hz
- Life Time: 30,000hours
- Df: >0.9
-
-
1.Terminal block should be used for connecting the supply cord, which is not includedin this package. The terminal block must comply with IEC/EN 60998-1,IEC/EN60998-2-1 or IEC/EN 60998-2-2and fulfill IP20 protection:
-The terminal block is 3 poles;
-The terminal block capacity is 0.5-1m㎡;
-The rated voltage of terminal block must not less than 250V;
-The wire end must clamped by crimp terminal wire connector to prevent the free wire conductor escaping;
-Terminals providing doubule insulation doesn't need to be fixed.
2.The external flexible cable or cord of this luminaire cannot be replaced; if the cord isdamaged, the luminaire shall be destroyed.
3.The light source contained in this luminaire shall only be replaced by themanufacturer or his service agent or a similar qualified person.
