CE-TD6008

Category： LED DOWN LIGHT
CCT:3000K/4000K/6500K
Power: 60W
Rate luminous flux (lumen) : 4800lm
Ra: ≥80
Luminous Efficency: 80lm/W
Input Voltage: 220-240V~,50/60Hz
Life Time: 30,000hours
Df: >0.9
INQUIRY EMAIL

1.Terminal block should be used for connecting the supply cord, which is not includedin this package. The terminal block must comply with IEC/EN 60998-1, IEC/EN60998-2-1 or IEC/EN 60998-2-2,and fulfill IP20 protection:

-The terminal block is 3 poles；

-The terminal block capacity is 0.5-1m㎡ ;

-The rated voltage of erminal block must not less than 250V;

-The wire end must clamped by crimp terminal wire connector to prevent the freewire conductor escaping;

-Terminals providing doubule insulation doesn't need to be fixed.

2.The external flexible cable or cord of this luminaire cannot be replaced; if the cord isdamaged, the luminaire shall be destroyed.

3.The light source contained in this luminaire shall only be replaced by themanufacturer or his service agent or a similar qualified person.
